Printer banding: stripes across your prints?
Banding means repeating light or dark stripes. Compare the file, print settings and your printer’s built-in check before choosing a fix.
Last updated: November 6, 2026
What does the banding look like?
Step 1 of 2Next check
Regular spacing is a clue to record, not proof of blocked nozzles or a particular failed part. Start with the check for your printer type.
- 1Inkjet: run the built-in nozzle check described in your exact model’s manual. Our downloaded PDF does not run that diagnostic.
- 2If the built-in pattern is incomplete, follow that model’s maintenance instructions. Laser: use its internal quality report and troubleshooting guide instead of nozzle cleaning.
- 3Compare a small PDF job from the same app. Note stripe direction, spacing, paper and settings.
Next check
Check paper, media settings and quality before assigning the bands to a component. The same appearance can have different causes.
- 1Match the paper type setting to supported paper. If using draft or fast mode, compare a higher quality setting offered by your printer.
- 2Check that paper is flat, dry and loaded squarely.
- 3Reprint the black-and-white test page to see whether the bands repeat.
Next check
Compare visible steps in the source gradient with stripes introduced in the printed output. One successful test does not rule out every printer issue.
- 1Print the photo test page and look at the smooth gradients.
- 2Use supported paper and its matching media setting; compare the same file with a higher quality option if available.
- 3Compare visible color output on the color test page. Missing color is an observation, not identification of a physical nozzle.
What the checks distinguish
Partly blocked nozzles (inkjet)
An inkjet’s built-in nozzle pattern can help decide whether its documented maintenance is needed. Follow the model manual; gaps in our ordinary PDF cannot identify individual nozzles.
Draft or fast quality setting
Quality and speed settings can affect visible output. Compare an available higher quality setting; how a mode works depends on the printer.
Uneven paper feed
Check that the media is supported, loaded in the documented orientation and matched by the paper-type setting. Inspect loading before treating stripes as a feed fault.
Laser drum, toner or fuser issues
A laser’s model-specific quality guide may use repeated-defect spacing to narrow the checks. Record spacing and feed direction; do not identify or replace a part from spacing alone.
What to try, in order
- 1Compare a small print jobOpen the black-and-white test PDF in the same app as the problem file. Record stripes, their spacing and whether another file shows them too. For color-only bands, compare the color test.
- 2Raise print qualityMatch the media setting to supported paper. If draft or fast mode is selected, compare an available higher quality mode with the same file and paper.
- 3Use the built-in diagnosticInkjet: follow the exact model’s built-in nozzle-check and maintenance instructions. Laser: use its internal quality report and documented supply/media checks. Our PDF is an output comparison, not either built-in procedure.
- 4Check paper and reprintLoad supported paper as the manual describes, then compare the same job. Keep the before/after sheets and settings; persistent spacing is evidence to share with model-specific support, not a parts diagnosis.
Use the exact model’s maintenance procedure, limits and waiting periods. Do not start or repeat cleaning solely because our PDF has stripes; compare the built-in diagnostic as the manufacturer directs.
When to contact support
If bands persist after the checks your manual recommends, contact the manufacturer with your model, paper, app, settings, comparison prints and built-in report. Record spacing and feed direction if marks repeat. An unresolved stripe pattern alone does not establish which part needs replacement or whether the printer should be replaced.
Inkjet or laser?
Inkjet printers
Use the printer’s built-in nozzle check and its exact-model interpretation before maintenance. A downloaded sheet can show visible output gaps but cannot isolate physical nozzles or run the printer’s diagnostic.
Read nozzle-check guidanceLaser printers
Laser printers do not use inkjet nozzle cleaning. Compare the internal quality report, supported paper and media settings. Repeated spacing can help model-specific troubleshooting, but it does not prove a drum, roller or fuser fault.
Print the black-and-white test pageHow do I fix color banding?
Match the media setting to supported paper and compare the same file at a higher quality setting if available. On an inkjet, use your model’s built-in nozzle diagnostic before deciding on maintenance. Also compare the source image with the print: visible gradient steps in a file are a different observation from stripes introduced in output.
- Printed stripes: compare another file from the same app, using the same paper and settings. Note whether stripes recur and where they appear.
- Gradient banding: visible steps appear in a smooth gradient, and may be in the image file or on the screen.
- Comparison: if our photo test page prints smoothly, that job did not show the same problem. It does not prove that every file, setting or printer function is healthy.
Banding is a pattern of light and dark stripes running across the page. It is most visible in photos, gradients and large solid areas, which is why a text document may look fine while a photo looks striped.
Find the pattern first
For an inkjet, run the built-in nozzle check from the printer or its maintenance utility as your exact model’s manual directs. Our downloaded nozzle sheet is an ordinary PDF: gaps are visible output observations, not a map of individual physical nozzles. The nozzle-check reading guide explains the distinction. Use the photo test page to compare visible gradients, not to certify that the printer is fault-free.
For a laser, use its internal quality report and model-specific troubleshooting. The black-and-white PDF provides a separate computer-sent comparison. Record stripe spacing and the direction the paper feeds. Those observations can help support staff, but cannot identify a roller, drum or fuser by themselves.
Settings that cause banding
Quality and speed controls differ by model. If draft or fast mode is selected, compare an available higher quality option using the same file and paper. Match the media setting to supported paper; do not assume every quality mode uses the same number of passes or amount of ink. For cardstock, see our cardstock guide. Our Windows and Mac guides cover print workflows.
Paper and feed
Check the manual’s supported media, printable-side orientation and loading instructions. Compare using flat, suitable paper and record the settings. A changed result is useful evidence, but does not prove a feed mechanism is faulty. If the page also looks doubled, see misaligned print.
Model-specific diagnostic examples
Epson’s WF-C20600/WF-C20750/WF-C21000/WF-M21000 guidance covers a built-in nozzle check, matching media settings and quality adjustments for those models. Use the associated built-in check instructions only where they apply; maintenance limits are model-specific.
HP’s quality guide for LaserJet Enterprise M406/M407/MFP M430/M431 and Managed E40040/E42540 uses model-specific repeated-defect checks involving multiple assemblies. Do not apply its component measurements to another printer or replace a part from our PDF alone.
Related problems
Thin lines rather than wide bands are covered in streaks or lines. Overall pale prints are in faded print. The alignment test page helps if bands come with shifted or doubled edges.
To compare smooth tones, use the grayscale test page. The grid test page can show visible line distortion or spacing differences, but does not establish a paper-feed cause.
